Adjust Flat CeramTip
309856A 15
Adjust Flat CeramTip
WARNING
Read warnings, page 8.
1.
Engage safety lock, page 11.
2.
Close fluid valves A and B.
TI3850a
TI3837a
U
A
B
3.
Remove air cap (9).
4.
Using nut driver, position CeramTip as desired.
5.
Reassemble air cap (9) fingertight.
9
TI3854a
TI3867a
