Graco A Series Instructions - Parts

Parts
46 309856A
CeramTip Kits
Round CeramTip Part Numbering Code
Round CeramTips (include drill bit)
**For further information, see identification chart under
Drill Bit Kits
, page 47.
Flat CeramTip Part Numbering Code
Flat CeramTips
Example
Part No.
First Three Digits Last Three Digits
RTM055 RTM
=Round CeramTip mechanical purge Equivalent orifice diameter size (.
055
in.)
CeramTip Part No. Drill Bit Size, nominal**
RTM024 #73
RTM030 #67
RTM040 #60
RTM055 #54
RTM070 #50
RTM080 2.0 mm
RTM090 #43
RTM100 #39
RTM110 7/64
Example
Part No.
First Three Digits Fourth Digit Last Two Digits
FTM848 FTM
=Flat CeramTip mechanical purge
8
x2=pattern length
(
8
x2=16 in.)
Equivalent orifice diameter size
(.0
48
in.)
CeramTip Part No. Pattern Size, in. (mm)
FTM317 very low flow, 6-8 (152-203)
FTM424 low flow, 8-10 (203-254)
FTM438 medium flow, 8-10 (203-254)
FTM624 low flow, 12-14 (305-356)
FTM638 medium flow, 12-14 (305-356)
FTM838 medium flow, 16-18 (406-457)
FTM848 high flow, 16-18 (406-457)
