Graco A Series Instructions - Parts

Parts
48 309856A
Gun Repair Kits
Read the chart left to right and top to bottom to find the quantity of each part in the kits.
Check Valve Filter Screen Kits (10 per kit)
80 mesh filter screen is standard with gun.
246357 40 mesh (.015 in., 375 micron)
246358 60 mesh (.010 in., 238 micron)
246359 80 mesh (.007 in., 175 micron)
Ref.
No.
246351
Check Valve
O-ring Kit
246354
O-ring
Multi-Kit
248000
Complete
O-ring Kit
248003
Purge Rod
Seal Kit
248095
Purge Rod
O-ring Kit
248096
Piston Shaft
O-ring Kit
14 1
16 1
18 2 3
19 1 3
20 1
21 1
24 5 4
36f 2
36g 2
46 4
