Maintenance
26
309856A
Adjust Fr
ont Rod Seal
If fluid m
isting occ
urs from tip w
hen gun is
not tri
ggered,
use f
ollowing p
rocedure to te
mporaril
y stop leakag
e until
par
ts
are replace
d.
1.
Fo
l
l
ow
Pressu
re Relief Procedure
, page 17.
2.
Back out purge r
od 1-2 tur
ns wi
th nut dr
iv
er
.
TI3828a
3.
Remov
e air cap
(9).
4.
T
r
igger gun an
d hold.
Tighten retai
ner (28) an
addi-
tional notc
h.
5.
Detr
igger gun.
Reassemble air cap
(9) finger
tight.
6.
Adjust Purge Rod
, page 14.
9
TI3854a
28
25
27
