Graco A Series Instructions - Parts

Parts
309856A 45
Direct Impingement Round Pattern Guns
Direct Impingement Flat Pattern Guns
**For further information, see identification chart under
Drill Bit Kits
, page 47.
Polycarballoy Mix
Module Kit
(includes drill bits)
No. of
Impingement
Ports
Impingement
Port Drill Bit
Size, nominal**
XR2929 1 #69
XR3535 2 #73
XR4747 2 #67
XR5757 3 #67
Polycarballoy
Mix Module Kit
(includes drill
bits)
No. of
Impingement
Ports
Impingement
Port Drill Bit
Size, nominal**
Counterbore
Drill Bit Size,
nominal**
XF1313 1 #81 #67
XF1818 1 #77 #67
XF2929 1 #69 N/A
XF3535 2 #73 N/A
XF4747 2 #67 N/A
XF5757 3 #67 N/A
