Graco h30 - Electrical Connections and Wiring; Required Power and Plugs

Electrical Connections and Wiring
3A9286B 17
Electrical Connections and Wiring
Required Power and Plugs
NOTE: For equipment provided with a cable and flying
leads (no plug), install a main electrical disconnect per
local codes and regulations.
NOTE: Use adapters as needed. Follow local codes
and regulations.
To avoid injury from fire, explosion, or electric
shock, all electrical wiring must be done by a
qualified electrician and comply with all local codes
and regulations.
Required Power and Plugs
Location
Motor
Configuration
Code*
Model
Power Requirements
Cord/Cable
Termination
Plug
Input
Voltage
Phase
‡
Hertz Current
Ordinary
Locations
FF1
h30 (QUC),
h80 (QHD),
h120 (QHE)
200–240 V 3 50/60 Hz 7.5 A
NEMA L15-20
Plug
FF2
h30 (QHC)
200–240 V 1 50/60 Hz 10 A
IEC 60320-C14
Plug
✦
h80 (QHD),
h120 (QHE)
200–240 V 1 50/60 Hz 15 A
IEC 60320-C20
Plug
✦
FF5 h30 (QHC)
100–120 V 1 50/60 Hz 12 A
NEMA 5-15 Plug
Hazardous
(Classified)
Locations
FF3
h30 (QHC),
h80 (QHD),
h120 (QHE)
200–240 V 3 50/60 Hz 7.5 A
Flying Leads, see
F
IG. 10
For
permanent
connection
■
FF6 h30 (QHC)
100–120 V 1 50/60 Hz 12 A
Flying Leads, see
F
IG. 9
Explosive
Atmospheres
FF4
h30 (QHC)
200–240 V 1 50/60 Hz 10 A
Flying Leads, see
F
IG. 9
h80 (QHD),
h120 (QHE)
200–240 V 1 50/60 Hz 15 A
* See Configuration Matrix, starting on page 7, for detailed descriptions.
‡
Connect to a circuit with a main electrical disconnect. Install a branch circuit protective device in each ungrounded phase.
Follow local codes and regulations.
■
See Wire Power Cables, page 18.
✦
Adapters are available (purchase separately). See Adapters for Plugs and Cables, page 19.
