Graco h30 - Technical Specifications for H120 (QHE) Models

Technical Specifications
3A9286B 51
Technical Specifications for h120 (QHE) Models
QUANTM h120 (QHE) Pumps
US Metric
Maximum fluid working pressure 60 psi 6.89 bar, 0.69 MPa
Maximum free-flow delivery 120 gpm 378.5 lpm
Maximum size pumpable solids
High Sanitation models 0.5 in. 12.7 mm
All other models 0.25 in. 6.35 mm
Environmental temperature range 0° to 104°F –18° to 40°C
Maximum operating altitude 9842 ft 3000 m
Electrical ratings
Rated Voltage Phase Hertz Current
h120 (QHE) models, FF1 motor 200–240 V 3 50/60 Hz 7.5 A
h120 (QHE) models, FF2 motor 200–240 V 1 50/60 Hz 15 A
h120 (QHE) models, FF3 motor 200–240 V 3 50/60 Hz 7.5 A
h120 (QHE) models, FF4 motor 200–240 V 1 50/60 Hz 15 A
Materials of construction
See Configuration Matrix, starting on page 7, for materials of construction for your equipment model.
Fluid inlet/outlet sizes
Inlet/Outlet size for models with wetted section
materials coded:
HS, PH, 3A 2 in. sanitary flange or 50 mm DIN 11851, male threads
Inlet size for models with wetted section materials
coded:
FG (models for ram mounting) 4 in. sanitary flange
FG (all other FG models)
2.5 in. sanitary flange or 65 mm DIN 11851,
or 2.1 in. for ram mounting models only
Outlet size for models with wetted section
materials coded:
FG (models for ram mounting) 3 in. sanitary flange
FG (all other FG models)
2.5 in. sanitary flange or 65 mm DIN 11851
or 1.8 in. for ram mounting models only
Maximum suction lift*
Wet 18.0 ft 5.48 m
Dry 15.9 ft 4.8 m
Noise (dBa)
Maximum sound pressure 77 dBa at full power and full flow
Sound pressure measured 1.6 feet (0.5 meter) from equipment.
Sound power measured per ISO-9614-2.
Weight
Models with wetted section materials coded:
FG 170 lb 77.1 kg
HS, PH, 3A 143 lb 64.9 kg
Notes
* May vary based on pump materials, suction condition, discharge head, pressure, and fluid type.
