Graco h30 - Technical Specifications for H30 (QHC) Models

Technical Specifications
3A9286B 49
Technical Specifications for h30 (QHC) Models
QUANTM h30 (QHC) Pumps
US Metric
Maximum fluid working pressure 100 psi 6.89 bar, 0.69 MPa
Maximum free-flow delivery 30 gpm 114 lpm
Maximum size pumpable solids
High Sanitation models 0.42 in. 20.7 mm
All other models 1/8 in. 3.2 mm
Environmental temperature range 0° to 104°F –18° to 40°C
Maximum operating altitude 9842 ft 3000 m
Electrical ratings
Rated Voltage Phase Hertz Current
h30 (QHC) models, FF1 motor 200–240 V 3 50/60 Hz 7.5 A
h30 (QHC) models, FF2 motor 200–240 V 1 50/60 Hz 10 A
h30 (QHC) models, FF3 motor 200–240 V 3 50/60 Hz 7.5 A
h30 (QHC) models, FF4 motor 200–240 V 1 50/60 Hz 10 A
h30 (QHC) models, FF5 motor 100–120 V 1 50/60 Hz 12 A
h30 (QHC) models, FF6 motor 100–120 V 1 50/60 Hz 12 A
Materials of construction
See Configuration Matrix, starting on page 7, for materials of construction for your equipment model.
Fluid inlet/outlet sizes
Models with wetted section materials coded:
FG 1.5 in. sanitary flange or 40 mm DIN 11851
HS, PH, 3A 1.0 in sanitary flange or RD52 x 1/6 DIN
Maximum suction lift*
Wet 29.0 ft 8.8 m
Dry 7.9 ft 2.4 m
Noise (dBa)
Maximum sound pressure 74 dBa at full power and flow
Sound pressure measured 1.6 feet (0.5 meter) from equipment.
Sound power measured per ISO-9614-2.
Weight
Models with wetted section materials coded:
FG 88 lb 39.9 kg
HS, PH, 3A 77 lb 34.9 kg
Notes
* May vary based on pump materials, suction condition, discharge head, pressure, and fluid type.
All trademarks or registered trademarks are the property of their respective owners.
