Technical Specifications
50 3A9286B
Technical Specifications for h80 (QHD) Models
QUANTM h80 (QHD) Pumps
US Metric
Maximum fluid working pressure 100 psi 6.89 bar, 0.69 MPa
Maximum free-flow delivery 80 gpm 227 lpm
Maximum size pumpable solids
High Sanitation models, ball checks 0.5 in. 12.7 mm
High Sanitation models, flapper checks 1.2 in. 30.5 mm
All other models 0.19 in. 4.8 mm
Environmental temperature range 0° to 104°F –18° to 40°C
Maximum operating altitude 9842 ft 3000 m
Electrical ratings
Rated Voltage Phase Hertz Current
h80 (QHD) models, FF1 motor 200–240 V 3 50/60 Hz 7.5 A
h80 (QHD) models, FF2 motor 200–240 V 1 50/60 Hz 15 A
h80 (QHD) models, FF3 motor 200–240 V 3 50/60 Hz 7.5 A
h80 (QHD) models, FF4 motor 200–240 V 1 50/60 Hz 15 A
Materials of construction
See Configuration Matrix, starting on page 7, for materials of construction for your equipment model.
Fluid inlet/outlet sizes
Models with wetted section materials coded:
FG 2.0 in. sanitary flange or 50 mm DIN 11851
HS, PH, 3A 1.5 in. sanitary flange or 40 mm DIN 11851, male thread
Maximum suction lift*
Wet 18.0 ft 5.48 m
Dry 19.3 ft 5.9 m
Noise (dBa)
Maximum sound pressure 72 dBa at full power and full flow
Sound pressure measured 1.6 feet (0.5 meter) from equipment.
Sound power measured per ISO-9614-2.
Weight
Models with wetted section materials coded:
FG 120 lb 54.4 kg
HS, PH, 3A 98 lb 44.5
Notes
* May vary based on pump materials, suction condition, discharge head, pressure, and fluid type.
All trademarks or registered trademarks are the property of their respective owners.
