Graco Reactor 2 H-XP3 Repair Manual

Parts
Fluid Fluid
Fluid
Manifold Manifold
Manifold
1
Torqueto355–395in.-lbs(40–44.6N●m)
2
Applysealant(113500)tothreads.
3
Valvemustbeclosedwithhandlepositionas
shownondrawing.
4
ApplyPTFEtapeandthreadsealanttogauge
threads.
5
Applygreaseonvalve.
6.
ApplyPTFEtapeorthreadsealanttoalltapered
threads.
Ref Ref
Ref
Part Part
Part
Description Description
Description
Qty Qty
Qty
401255228
MANIFOLD,󰘱uid
1
402◊247824KIT,valve,cartridge,drain2
402a◊158674
O-RING,BUNA-N(not
shown)
1
402b◊247779
SEAL,seat,valve(not
shown)
1
403102814
GAUGE,press,󰘱uid
2
404162453
FITTING,1/4NPSMX1/4
NPT
2
40515M669
SENSOR,pressure,󰘱uid
outlet
2
406247788HANDLE,red1
407247789HANDLE,blue1
408112309NUT,hex,jam2
411117556
NIPPLE,#8JICx1/2NPT
1
Ref Ref
Ref
Part Part
Part
Description Description
Description
Qty Qty
Qty
412121309
FITTING,3/4SAEx1/2
JIC
2
413100840
FITTING,elbow,street
2
414111457
O-RING,PTFE
2
415▲189285
LABEL,hotsurface
1
416150829
SPRING,compression
2
419117557
NIPPLE,#10JICx1/2
NPT
1
▲
Replacement Warning labels, signs, tags,
and cards are available at no cost.
◊
Included in the following complete valve kits:
ISO Valve Kit (left/red) handle 255149.
Resin Valve Kit (right/blue handle) 255150.
Valve Set Kit (both handles and grease gun)
255148.
334946C 83
