Graco Reactor 2 H-XP3

Parts
Heater Heater
Heater
Parts Parts
Parts
17G646, 17G646,
17G646,
7.5kw 7.5kw
7.5kw
Single Single
Single
Zone Zone
Zone
Heater Heater
Heater
17G648, 17G648,
17G648,
10.2 10.2
10.2
kw kw
kw
Single Single
Single
Zone Zone
Zone
Heater Heater
Heater
1
Torqueto120ft-lbs(163N•m).
2
Torqueto23ft-lbs(31N•m).
3
Applythermalpaste.
4.
ApplypipesealantandPTFEtapetoall
non-swivelingthreadsandthreadswithout
o-rings.
5
Applylithiumgreaselubricanttoo-ringsbefore
assemblinginblock(501).
6
Orientatesensorasshown.Insertprobeuntilit
bottomsonheatingelement.Tightenferruleon
sensorprobeoneturnpast󰘰ngertightor180
in-lbs(20.3N•m).
8
Orientrupturedischousing(514)withexhaust
holepointingawayfrom󰘰tting(508).
84 334946C
