Graco Reactor 2 H-XP3 Repair Manual

Parts
Fluid Fluid
Fluid
Inlet Inlet
Inlet
Kits Kits
Kits
17G644, 17G644,
17G644,
Standard Standard
Standard
1
Orientateballvalvesasshown.
2
Applytapetothreadsofhousing.
3
Applythermallubricantcompletelycovering
thermometerprobe(904)beforeinsertinginto
housing(910).
4
Applygreasetoo-ring(907).
5.
Applysealanttoalltaperedpipethreads.Apply
sealanttofemalethreads.Brushinto,atleast,
the󰘰rstfourthreadsandapproximately1/4turn
wide.
6.
Orientategaugesverticallywithinassembly.
Ref. Ref.
Ref.
Part Part
Part
Description Description
Description
Qty. Qty.
Qty.
901118459
FITTING,union,swivel
3/4in.
4
90216W714
MANIFOLD,strainer,
inlet
2
903
C20487FITTING,nipple,hex
2
90416W117
THERMOMETER,dial
2
90516T872
GAUGE,pressure,󰘱uid
2
906180199FILTER,replacent2
907128061
PACKING,o-ring,FX75
2
Ref. Ref.
Ref.
Part Part
Part
Description Description
Description
Qty. Qty.
Qty.
90816V879
CAP,󰘰lter
2
909555808
PLUG,1/4mpwithhex
hd
2
91015D757
HOUSING,thermometer
2
911109077VALVE,ball3/4npt2
912253481
GUARD,gauge,
y-strainer
2
913111800
SCREW,cap,hexhd;
5/8in.,5/16–18
4
86 334946C
