Graco Reactor 3 Repair And Parts

4 3A8501A
Models
Reactor E-20 and E-30
Model (Part Number)
E-20 Standard
7 kW (26R310)
E-20 Pro 7
kW (26R311)
E-20 Pro 10
kW (26R313)
E-20 Elite 10
kW (26R312)
E-30 Standard
10 kW (26R330)
E-30 Pro 10
kW (26R331)
E-30 Pro 15
kW (26R333)
E-30 Elite 15
kW (26R332)
Technical
Information
Maximum working
pressure
2000 psi
(14 MPa, 140
bar)
2000 psi
(14 MPa, 140
bar)
2000 psi
(14 MPa,
140 bar)
2000 psi
(14 MPa, 140
bar)
2000 psi
(14 MPa, 140
bar)
2000 psi
(14 MPa,
140 bar)
2000 psi
(14 MPa,
140 bar)
2000 psi
(14 MPa, 140
bar)
Approximate output /
cycle A + B
0.0104 gal
(0.0395 L)
0.0104 gal
(0.0395 L)
0.0104 gal
(0.0395 L)
0.0104 gal
(0.0395 L)
0.0273 gal
(0.103 L)
0.0273 gal
(0.103 L)
0.0273 gal
(0.103 L)
0.0273 gal
(0.103 L)
Maximum flow 20 lb/min
(9.1 kg/min)
20 lb/min
(9.1 kg/min)
20 lb/min
(9.1 kg/min)
20 lb/min
(9.1 kg/min)
30 lb/min
(13.5 kg/min)
30 lb/min
(13.5 kg/min)
30 lb/min
(13.5 kg/min)
30 lb/min
(13.5 kg/min)
Max heated hose length
supported
220 ft
(67 m)
220 ft
(67 m)
220 ft
(67 m)
220 ft
(67 m)
320 ft
(97.5 m)
320 ft
(97.5 m)
320 ft
(97.5 m)
320 ft
(97.5 m)
Total system load 12.9 kW 12.9 kW 15 kW 15 kW 17.5 kW 17.5 kW 22.3 kW 22.3 kW
Primary heater load 7.6 kW 7.6 kW 9.6 kW 9.6 kW 9.6 kW 9.6 kW 14.4 kW 14.4 kW
Full load
peak
current
200-240
VAC 1
phase
56 A 56 A 65 A 65 A 76 A 76 A 97 A 97 A
200-240
VAC 3
phase delta
36 A 36 A 39 A 39 A 49 A 49 A 59 A 59 A
350-415
VAC 3
phase Y
24 A 24 A 24 A 24 A 35 A 35 A 35 A 35 A
System
Features
Ratio monitoring
✓ ✓
Reactor Connect app
✓ ✓ ✓ ✓ ✓ ✓
Large-ported
recirculation valves
✓ ✓ ✓ ✓ ✓ ✓
Software includes
auto-pressure
balancing and power
management
✓ ✓ ✓ ✓ ✓ ✓
Tank-level dip sticks
✓ ✓ ✓ ✓ ✓ ✓
Large inlet strainer with
gauge, pressure, and
temperature sensors
✓ ✓
Large inlet strainer with
gauge
✓ ✓ ✓ ✓
Small inlet strainer with
no gauge
✓ ✓
Packages Externally heated hose
package, 1 x 50 ft
(15.24 m)
ESR310
★ ESR311★ ESR313★ ESR312◆• ESR330★ ESR331★ ESR333★ ESR332◆•
Externally heated hose
package, 2 x 100 ft
(30.48 m)
EHR310
★ EHR311★ EHR313★ EHR312◆• EHR330★ EHR331★ EHR333★ EHR332◆•
Internally heated hose
package, 1 x 50 ft
(15.24 m)
ISR310
★ ISR311★ ISR313★ ISR312◆• ISR330★ ISR331★ ISR333★ ISR332◆•
Internally heated hose
package, 2 x 100 ft
(30.48 m)
IHR310
★ IHR311★ IHR313★ IHR312◆• IHR330★ IHR331★ IHR333★ IHR332◆•
Core E1 with internally
heated hose package,
1 x 50 ft (15.24 m)
CSR312◆• CSR332◆•
Core E1 with internally
heated package,
2 x 100 ft (30.48 m)
CHR312◆• CHR332◆•
◆ Includes engine CAN diagnostic cable. • Includes 20 ft (6.1 m) whip hose. ★ Includes 10 ft (3.05 m) whip hose.
