Parts

68 3A8501A

Ship Loose Parts

+ Pro and Elite systems only.

ti41038a

77,78

A-64

B-65

Ref. Part Description Qty.

25T859 FLUID, TSL, 32 oz bottle

64+

24K409 BAR, 55 gallon chemical measure, A side

65+

24K411 BAR, 55 gallon chemical measure, B side

18C963 BRACKET, wall mount, left

18C964 BRACKET, wall mount, left

18D240 JACKET, scuff, R3, machine joint

206994 FLUID, TSL, 8 oz bottle

Table of Contents2
Supplied Manuals3
Related Manuals3
Models4
Reactor E-20 and E-304
Reactor E-XP1 and E-XP25
Approvals6
Accessories6
Warnings7
Important Isocyanate Information11
Isocyanate Conditions11
Material Self-Ignition12
Keep Components a and B Separate12
Changing Materials12
Moisture Sensitivity of Isocyanates12
Foam Resins with 245 Fa Blowing Agents12
Notes13
Component Identification14
Proportioner14
Electrical Enclosure16
Temperature Control Module (TCM)17
Motor Control Module (MCM)17
Advanced Display Module (ADM)18
Pressure Relief Procedure19
Shutdown20
Flush the Equipment21
Repair22
Before Beginning Repair22
Flush Inlet Strainer Screen22
Change ISO Pump Throat Seal Lubricant (TSL) Fluid23
Remove Pump24
Install Pump26
Motor Replacement27
Replace Circuit Breaker30
Replace Inlet Pressure Transducer31
Replace Inlet Temperature Sensor31
Replace Outlet Pressure Transducers32
Replace Fans32
Replace Flow Meter34
Repair Primary Heater35
Replace Over-Temperature Switch36
Replace RTD37
Troubleshoot Heated Hose38
Check Hose RTD Cables and FTS38
Repair Fluid Temperature Sensor (FTS)40
Calibration Procedure41
Transformer Check41
Replace Transformer42
Replace Power Supply43
Replace Surge Protector43
Replace Motor Control Module (MCM)44
Replace Temperature Control Module (TCM)44
Replace Advanced Display Module (ADM)45
Software Update Procedure45
Software Update Procedure USB46
Over-The-Air Software Updates47
Replace Fluid Outlet Manifold48
Notes49
Parts50
Top Level Units50
Drivers55
Heaters57
Manifolds59
Electrical Enclosures61
Inlet Strainers Parts63
Rail Module 247998 Parts65
Ship Loose Parts68
Electrical Schematics69
Recycling and Disposal76
End of Product Life76
California Proposition 6576
Technical Specifications77
Reactor E-2077
Reactor E-XP178
Reactor E-3079
Reactor E-XP280
Graco Extended Warranty for Reactor ® Components81
