Graco Reactor 3 Repair And Parts

Technical Specifications
3A8501A 77
Technical Specifications
Reactor E-20
Reactor 3 Proportioning Systems, E-20
U.S. Metric
Maximum Fluid Working Pressure
2000 psi 140 bar, 14 MPa
Maximum Fluid Temperature
160 °F 71.1 °C
Maximum Flow Rate
20 lb/min 9.07 kg/min.
Maximum Heated Hose Length
220 ft 67 m
Approximate Output Per Cycle (A+B)
0.0104 gal 39.4 cc
Operating Ambient Temperature Range
20 °F to 120 °F -7 °C to 49 °C
Fluid Inlets
3/4 npt(f)
Fluid Outlet – A
#8 (1/2 in.) JIC, with #5 (5/16 in.) JIC adapter
Fluid Outlet – B
#10 (5/8 in.) JIC, with #6 (3/8 in.) JIC adapter
Fluid Circulation Port Size
1/4 nps(m)
Fluid Circulation
Port Maximum Pressure
250 psi 17 bar, 1.7 MPa
Wetted Parts
Aluminum, stainless steel, zinc-plated carbon steel, nickel-plated carbon steel, brass,
tungsten carbide, chrome, chemically resistant o-rings, PTFE, acetal, ultra high
molecule weight polyethylene
Maximum Fluid Inlet Pressure
Standard
Models
Pro and Elite
Models
Standard
Models
Pro and Elite
Models
400 psi
600 psi
27.6 bar, 2.76 MPa 41.3 bar, 4.14 MPa
Line Voltage Requirement
200–240 VAC, 1–ph, 50/60 Hz
200–240 VAC, 3–ph DELTA, 50/60 Hz
350-415 VAC, 3-ph WYE, 50/60 Hz
Sound Pressure: Measured per ISO-9614-2
Measured from 3.1 ft (1 m) @ 3000 psi
(21 MPa, 207 bar), 1 gpm (11.4 lpm)
90.1 dBA
Sound Power:
Measured from 3.1 ft (1 m) @ 3000 psi
(21 MPa, 207 bar), 1 gpm (11.4 lpm)
97.15 dBA
Dimensions:
Width
24.9 in. 63 cm
Depth
15.0 in. 38 cm
Height
56.5 in. 144 cm
Weight:
Elite 10 kW
270 lb 122 kg
Notes:
