Graco Reactor 3 Repair And Parts

3A8501A 5
Reactor E-XP1 and E-XP2
Model (Part Number)
E-XP1 Standard
10 kW (26R320)
E-XP1 Pro 10
kW (26R321)
E-XP1 Elite 10
kW (26R322)
E-XP2 Standard
15 kW (26R340)
E-XP2 Pro 15
kW (26R341)
E-XP2 Elite (15
kW (26R342)
Technical
Information
Maximum working
pressure
3000 psi (20.7
MPa, 207 bar)
3000 psi (20.7
MPa, 207 bar)
3000 psi (20.7
MPa, 207 bar)
3500 psi (24.1
MPa, 241 bar)
3500 psi (24.1
MPa, 241 bar)
3500 psi (24.1
MPa, 241 bar)
Approximate output / cycle
A + B
0.0104 gal
(0.0395 L)
0.0104 gal
(0.0395 L)
0.0104 gal
(0.0395 L)
0.0204 gal
(0.0771 L)
0.0204 gal
(0.0771 L)
0.0204 gal
(0.0771 L)
Maximum flow 2 gpm
(7.6 lpm)
2 gpm
(7.6 lpm)
2 gpm
(7.6 lpm)
2.1 gpm
(7.9 lpm)
2.1 gpm
(7.9 lpm)
2.1 gpm
(7.9 lpm)
Maximum heated hose
length supported
220 ft
(67 m)
220 ft
(67 m)
220 ft
(67 m)
320 ft
(97.5 m)
320 ft
(97.5 m)
320 ft
(97.5 m)
Total system load 15 kW 15 kW 15 kW 22.3 kW 22.3 kW 22.3 kW
Primary heater load 9.6 kW 9.6 kW 9.6 kW 14.4 kW 14.4 kW 14.4 kW
Full load
peak
current
200-240 VAC
1 phase
65 A 65 A 65 A 97 A 97 A 97 A
200-240 VAC
3 phase delta
39 A 39 A 39 A 59 A 59 A 59 A
350-415 VAC
3 phase Y
24 A 24 A 24 A 35 A 35 A 35 A
System
Features
Ratio monitoring
✓ ✓
Reactor Connect app
✓ ✓ ✓ ✓
Large-ported recirculation
valves
✓ ✓ ✓ ✓
Software includes
auto-pressure balancing
and power management
✓ ✓ ✓ ✓
Tank-level dip sticks
✓ ✓ ✓ ✓
Large inlet strainer with
gauge, pressure, and
temperature sensors
✓ ✓
Large inlet strainer with
gauge
✓ ✓
Small inlet strainer with no
gauge
✓ ✓
Packages Externally heated hose
package,
1 x 50 ft (15.24 m)
ESR320★ ESR321★ ESR322◆• ESR340★ ESR341★ ESR342◆•
Externally heated hose
package,
2 x 100 ft (30.48 m)
EHR320★ EHR321★ EHR322◆• EHR340★ EHR341★ EHR342◆•
Internally heated hose
package,
1 x 50 ft (15.24 m)
ISR320
★ ISR321★ ISR322◆• ISR340★ ISR341★ ISR342◆•
Internally heated hose
package,
2 x 100 ft (30.48 m)
IHR320
★ IHR321★ IHR322◆• IHR340★ IHR341★ IHR342◆•
Core E1 with internally
heated hose package,
1 x 50 ft (15.24 m)
CSR322◆• CSR342◆•
Core E1 with internally
heated hose package,
2 x 100 ft (30.48 m)
CHR322◆• CHR342◆•
◆ Includes engine CAN diagnostic cable. • Includes 20 ft (6.1 m) whip hose. ★ Includes 10 ft (3.05 m) whip hose.
