Technical Specifications
3A8501A 79
Reactor E-30
Reactor 3 Proportioning Systems, E-30
U.S. Metric
Maximum Fluid Working Pressure
2000 psi 140 bar, 14 MPa
Maximum Fluid Temperature
160 °F 71.1 °C
Maximum Flow Rate
30 lb/min 13.5 kg/min.
Maximum Heated Hose Length
320 ft 97.5 m
Approximate Output Per Cycle (A+B)
0.0273 gal 103.4 cc
Operating Ambient Temperature Range
20 °F to 120 °F -7 °C to 49 °C
Fluid Inlets
3/4 npt(f)
Fluid Outlet – A
#8 (1/2 in.) JIC, with #5 (5/16 in.) JIC adapter
Fluid Outlet – B
#10 (5/8 in.) JIC, with #6 (3/8 in.) JIC adapter
Fluid Circulation Port Size
1/4 nps(m)
Fluid Circulation
Port Maximum Pressure
250 psi 17 bar, 1.7 MPa
Wetted Parts
Aluminum, stainless steel, zinc-plated carbon steel, nickel-plated carbon steel, brass,
tungsten carbide, chrome, chemically resistant o-rings, PTFE, acetal, ultra high
molecule weight polyethylene
Maximum Fluid Inlet Pressure
Standard
Models
Pro and Elite
Models
Standard
Models
Pro and Elite
Models
400 psi
600 psi
27.6 bar, 2.76 MPa 41.3 bar, 4.14 MPa
Line Voltage Requirement
200–240 VAC, 1–ph, 50/60 Hz
200–240 VAC, 3–ph DELTA, 50/60 Hz
350-415 VAC, 3-ph WYE, 50/60 Hz
Sound Pressure: Measured per ISO-9614-2
Measured from 3.1 ft (1 m) @ 3000 psi
(21 MPa, 207 bar), 1 gpm (11.4 lpm)
87.3 dBA
Sound Power:
Measured from 3.1 ft (1 m) @ 3000 psi
(21 MPa, 207 bar), 1 gpm (11.4 lpm)
93.7 dBA
Dimensions:
Width
26.8 in. 68 cm
Depth
15.0 in. 38 cm
Height
56.5 in. 144 cm
Weight:
Elite 15 kW
335 lb 151.9 kg
Notes:
