Graco Reactor 3 - Page 67

Parts
3A8501A 67
Rail Module Parts List (247998)
✖ Not shown.
Ref. Part Description Qty.
701
18D004 RAIL, mount, 18mm slot
1
702
18D005 BRACKET, din rail
1
703
116610 SCREW, mach, phil, pan, #10
4
704
113505 NUT, keps, hex hd
4
705
120838 BLOCK, clamp end
2
706
126453 POWER SUPPLY, 24V
1
707
17A314 CIRCUIT, breaker, 2p, 20a, ul489, ab
1
708
17A317 CIRCUIT, breaker, 2p, 40a, ul489, ab
3
709
17A319 CIRCUIT, breaker, 1p, 50a, ul1077, ab
1
710
132931 BLOCK, ground, terminal
1
711
24R724 BLOCK, terminal, ut35
6
712
132801 SWITCH, rotary disconnect, 3p, 100a
1
713
132802 SWITCH, fourth pole, 100a, ul98
1
714
133472 7-PIN connector, TCM
1
715
133471 3-PIN connector, MCM
1
716
133470 6-PIN connector, TCM
1
717
133469 3-PIN connector, TCM
1
724
125625 TIE, cable, fir tree
4
725
✖ 127369 SLEEVE, split, wire, 1.00 id
1
729
✖ 128036 SLEEVE, split, wire, 0.63 id
1
736
✖ 132322 CONTACT, connector, pin, size 8
2
737
✖ 132323 CONTACT, connector, socket, size 8
2
738
114225 TRIM, edge protection
1
739
16U530 MODULE, sys srg prot
1
