Graco Reactor 3 Repair And Parts

Parts
52 3A8501A
26R342 Parts List
Ref. Part Description
Qty.
26R310
26R311
26R312
26R313
26R320
26R321
26R322
26R330
26R331
26R332
26R333
26R340
26R341
26R342
1 25R456 FRAME, weldment, R3, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 25R747 ENCLOSURE, elec, r3, no-app, 6-15 kW
1
1 1 1
25P164 ENCLOSURE, elec, r3, w/app, 6-15 kW
1 1 1 1 1 1 1 1 1 1
3 19Y700 BRACKET, proportioner, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
4
25P864
PROPORTIONER, module, E-20,
Reactor 3
1 1 1 1 1 1 1
25P865
PROPORTIONER, module, E-30,
Reactor 3
1 1 1 1
25P866
PROPORTIONER, module, E-XP2,
Reactor 3
1 1 1
5 25P794 COVER, motor, fan, assembly
1 1 1 1 1 1 1 1 1 1 1 1 1 1
6 16W608 FITTING, elbow 8 jic swivel x 8 jicm
2 2 2 2 2 2 2
17Z749 FITTING, elbow, swpt, 08 x 08, mf, cs
2 2 2 2 2 2 2
7 16X224 COVER, front, 695, painted
2 2 2 2 2 2 2
16X220 COVER, front, plastic, painted
2 2 2 2 2 2 2
8 19Y596 TRANSFORMER, 4090va, 230/90
1 1 1 1 1 1 1
19Y595 TRANSFORMER, 2790va, 230/62
1 1 1 1 1 1 1
9 26B085 COVER, weldment, transformer
1 1 1 1 1 1 1 1 1 1 1 1 1 1
10 132561 FAN, 24 VDC, 80 mm square x 15 mm
1 1 1 1 1 1 1 1 1 1 1 1 1 1
11 25P748 HEATER, assy, 1-zone, a-side, 7.2 kW
1 1 1 1 1
25P745 HEATER, assembly, dual-zone, 7.6 kW
1 1
25P744 HEATER, assembly, dual-zone, 9.6 kW
1 1 1 1 1 1 1
12 25P749 HEATER, assy, 1-zone, b-side, 7.2 kW
1 1 1 1 1
13 18B270 HOSE, coupled, R3, fluid, -8 jic
1 1 1 1 1 1 1 1 1 2 2 2 2 2
14 18B271 HOSE, coupled, R3, fluid, -8 jic
1 1 1 1 1 1 1 1 1
15 121311 FITTING, connector, npt x jic
2 2 2 2 2 2 2
121310 FITTING, connector, npt x jic
2 2 2 2 2 2 2
16 118459 FITTING, union, swivel, 3/4 in.
2 2 2 2 2 2 2
2 2 2
16W967 FITTING, swivel, 3/4 npt x 1 npsm
2 2 2 2
17 19C283 HOUSING, outlet, assembly
1 1 1 1 1 1 1 1 1 1
25R471 HOUSING, outlet, assembly
1
1 1 1
18 25T976 STRAINER, R3, assembly, pair, pro
1 1 1 1 1 1
25T975 STRAINER,R3, assembly, pair, elite
1 1 1 1
18D520 KIT, accessory, inlet pair
1
18D475 KIT, accessory, inlet pair
1
1 1
19 25B549 METER, flow, R3, high pressure
2 2 2 2
20 25S076 LABEL, brand
1 1 1 1
25S075 LABEL, brand
1 1 1 1
25S077 LABEL, brand
1 1 1
25S078 LABEL, brand
1 1 1
21 18B682 CAP, hose, square
6 6 6 6 6 6 6 6 6 6 6 6 6 6
22 111800 SCREW, cap, hex hd
10 10 10 10 10 10 10 10 10 10 10 10 10 10
23 25T859 FLUID, TSL, 25 oz (750 ml)
2 2 2 2 2 2 2 2 2 2 2 2 2 2
