Graco Reactor 3 Repair And Parts

Parts
3A8501A 53
24 113796 SCREW, flanged, hex hd
10 10 10 10 10 10 10 10 10 10 10 10 10 10
25 111194 SCREW, cap flange hd
4 4 4 4 4 4 4 4 4 4 4 4 4 4
26† 125625 TIE, cable, fir tree
4 4 4 4 4 4 4 4 4 4 4 4 4 4
27 25T575 BRACKET, pivot, right, R3, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
28 25T573 BRACKET, pivot, left, R3, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
29 19Y569 SHIELD, pump rod
1 1 1 1 1 1 1 1 1 1 1 1 1 1
30 15C762 SHIELD, pump rod
1 1 1 1 1 1 1 1 1 1 1 1 1 1
31† 110637 SCREW, mach, panhead
2 2 2 2 2 2 2 2 2 2 2 2 2 2
32 19C041 BRACKET, R3, iso-lube, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
33 18C779 CAP, bottle, TSL
1 1 1 1 1 1 1 1 1 1 1 1 1 1
34 503128 HOSE, polyethylene 1/4 od
7.5 feet (2.3 m)
35 18C187 PANEL, back, R3
1 1 1 1 1 1 1 1 1 1 1 1 1 1
36 132560 GUARD, finger, 80 mm fan
1 1 1 1 1 1 1 1 1 1 1 1 1 1
37 118444 SCREW, mach, slot hex wash hd
16 16 16 16 16 16 16 16 16 16 16 16 16 16
38 110996 NUT, hex, flange head
2 2 2 2 2 2 2 2 2 2 2 2 2 2
39 110631 SCREW, socket, hd
4 4 4 4 4 4 4 4 4 4 4 4 4 4
40 18B272 HOSE, coupled, R3, fluid, -8 jic
2 2 2 2 2 2 2 2 2 2 2 2 2 2
41 117502 FITTING, reducer #5 x #8 (jic)
1 1 1 1 1 1 1 1 1 1 1 1 1 1
42 117677 FITTING, reducer #6 x #10 (jic)
1 1 1 1 1 1 1 1 1 1 1 1 1 1
43 16W654 INSULATOR, foam, heater
2 2 2 2 2 2 2 4 4 4 4 4 4 4
44 18D006 FITTING, 1/8 in. npt, 1/16 in. npt
2 2 2 2 2 2 2 2 2 2 2 2 2 2
45† 113161 SCREW, flange, hex hd
8 8 8 8 8 8 8 8 8 8 8 8 8 8
46 114225 TRIM, edge protection
1 1 1 1 1 1 1 1 1 1 1 1 1 1
47† 132478 CABLE, thermistor
2 2 2 2
48† 18C473 CABLE, gca, m/f, 1.2m
2 2 5 2 2 2 5 2 2 5 2 2 2 5
49† 132477 CABLE, over-temp, heater, dual
1 1 1 1 1
132476 CABLE, over-temp, heater, single
1 1 1 1 1 1 1 1 1
51 18C657 INSULATOR, insolex, 0.75 id x 1.5 od
2 2 2 2 2 2 2 2 2 2 2 2 2 2
53 29A420 ARTWORK, identification
1 1 1 1 1 1 1 1 1 1 1 1 1 1
54 16U530 MODULE, sys srg prot
1 1 1 1 1 1 1 1 1 1 1 1 1 1
55 16W043 HOSE, pressure relief
2 2 2 2 2 2 2 2 2 2 2 2 2 2
56 25B521 FITTING, compression, adapt, 90, 1/4 in.
2 2 2 2 2 2 2 2 2 2 2 2 2 2
57 26B665 COVER, R3, lower-top, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
58 26B666 COVER, R3, lower-bottom, painted
1 1 1 1 1 1 1 1 1 1 1 1 1 1
59 119865 SCREW, mach, hex serrated
4 4 4 4 4 4 4 4 4 4 4 4 4 4
60 C19817 SCREW, cap, sch
3 3 3 3 3 3 3 3 3 3 3 3 3 3
61 18C658 GASKET, manifold
1 1 1 1 1 1 1 1 1 1 1 1 1 1
62† 103147 PLUG, pipe
4 4 4 4 4 4 4 4 4 4 4 4 4 4
63 25B524 CLIP, t-clip, snap-in
2 2 2 2 2 2 2 2 2 2 2 2 2 2
64† 24K409 BAR, 55 gal chem. meas. a side
1 1 1 1 1 1 1 1 1 1
65† 24K411 BAR, 55 gal chem. meas. b side
1 1 1 1 1 1 1 1 1 1
66† 24R725 BRIDGE, plug-in jumper, ut35
4 4 4 4 4 4 4 4 4 4 4 4 4 4
67† 299520 CAP, 9/16-18 jic cap-aluminum
1 1 1 1 1 1 1 1 1 1 1 1 1 1
68† 299521 CAP, 1/2-20 jic cap-aluminum
1 1 1 1 1 1 1 1 1 1 1 1 1 1
Ref. Part Description
Qty.
26R310
26R311
26R312
26R313
26R320
26R321
26R322
26R330
26R331
26R332
26R333
26R340
26R341
26R342
