Parts
54 3A8501A
† Not shown.
▲ Replacement safety labels, tags, and cards are available at no cost.
69† 132482 CABLE, reed switch
1 1 1 1 1 1 1 1 1 1 1 1 1 1
70† 132518 HARNESS, fan, transformer
1 1 1 1 1 1 1 1 1 1 1 1 1 1
71† 133231 CONNECTOR, plug, 7.62 mm, 4-position
1 1 1 1 1 1 1 1 1 1 1 1 1 1
72†
132484
CONNECTOR, plug, 3.81 mm
(8 position)
1 1 1 1 1 1 1 1 1 1 1 1 1 1
73†
132485
CONNECTOR, plug, 10.16 mm
(8 position)
1 1 1 1 1 1 1 1 1 1 1 1 1 1
74† 17E439 SUPPRESSOR, ferrite, dia. 400
1 1 1 1 1 1 1 1 1 1 1 1 1 1
75† 15D906 SUPPRESSOR, round snap ferrite .260
1 1 1 1 1 1 1 1 1 1 1 1 1 1
76† 25T997 LABEL, identification
1 1 1 1 1 1 1 1 1 1 1 1 1 1
77† 18C963 BRACKET, wall mount, left
1 1 1 1 1 1 1 1 1 1 1 1 1 1
78† 18C964 BRACKET, wall mount, right
1 1 1 1 1 1 1 1 1 1 1 1 1 1
79
▲
25T998 LABEL, safety
1 1 1 1 1 1 1 1 1 1 1 1 1 1
80† 127553 FITTING, straight, 1/4t x 1/8 npt
1 1 1 1 1 1 1 1 1 1 1 1 1 1
81 112738 GROMMET
2 2 2 2 2 2 2 2 2 2 2 2 2 2
82† 133212 LABEL, self laminating
1 1 1 1 1 1 1 1 1 1 1 1 1 1
83 29A382 ARTWORK, identification
1 1 1 1 1 1 1 1 1 1 1 1 1 1
85† 127111 ENVELOPE, packing, self-adhesive
1 1 1 1 1 1 1 1 1 1 1 1 1 1
86† 18E151 LABEL, installation
1 1 1 1 1 1 1 1 1 1 1 1 1 1
87† 18D240 JACKET, scuff, R3, machine joint
1 1 1 1 1 1 1 1 1 1 1 1 1 1
88† 17R703 CABLE, gca, m/f, 0.3m
2 2 2 2
89† 25E540 CONNECTOR, splitter
1 1 1 1
90 29A376 ARTWORK, identification
1 1 1 1 1 1 1 1 1 1 1 1 1 1
91† 125871 TIE, cable, 7.5 in.
1 1 1 1 1 1 1 1 1 1 1 1 1 1
92 18D314 SHIELD, membrane, ADM, 10-pack
1 1 1 1 1 1 1 1 1 1 1 1 1 1
93 206994 FLUID, TSL, 8 oz bottle
1 1 1 1 1 1 1 1 1 1 1 1 1 1
94 133416 STRAINER, suction, 1/4 npt
1 1 1 1 1 1 1 1 1 1 1 1 1 1
95 16E254 FITTING, connector, male, straight
1 1 1 1 1 1 1 1 1 1 1 1 1 1
98 132001 BOLT, flange hd, serrated, 3/8
4 4 4 4 4 4 4 4 4 4 4 4 4 4
101 112689 SCREW, button HD
3 3 3 3 3 3 3 3 3 3 3 3 3 3
Ref. Part Description
Qty.
26R310
26R311
26R312
26R313
26R320
26R321
26R322
26R330
26R331
26R332
26R333
26R340
26R341
26R342
