Parts
56 3A8501A
25P864, 25P865, and 25P866 Parts List
NOTE: See your pump repair manual for repair kits.
Not shown.
Replacement safety labels, tags, and cards are available at
no cost.
Included in A-side repair kits 18E197 (for E-20 and EXP1).
† Included in A-side repair kits 18E193 (for E-XP2), and
18E199 (for E-30).
‡ Included in B-side repair kits 18E198 (for E-20 and E-XP1).
Included in A-side repair kits 18E194 (for E-XP2) and
18E200 (for E-30).
Included in repair kit 18E138.
Ref. Part Description
Qty.
25P864 25P865 25P866
101 25P669 MOTOR, bldc, 2.5 hp, 2-end, 1-way
1 1
25P667 MOTOR, bldc, 1.75hp, 2-end, 1-way
1
102 114672 WASHER, thrust
4 4 4
103 243951 GEAR, combination,1595
2 2
243870 GEAR, combination
2
104 114699 WASHER, thrust
2 2 2
105 116192 WASHER, thrust, (1595)
2 2
116191 WASHER, thrust, (1095/795)
2
106 18D009 HOUSING, drive, E-20, R3
2
26C179 HOUSING, drive, R2, assembly
2 2
107 15C753 SCREW, mach, hex wash hd
10 10 10
108 240724 HOUSING, bearing
2
240014 HOUSING, bearing
2
245795 HOUSING, bearing
2
109 106115 WASHER, lock (hi-collar)
8 8 8
110 114666 SCREW, cap, socket head
8 8
17E788 SCREW, cap, sch, 3/8 x 1.5, sst
8
111 241278 ROD, connecting
2 2
287180 ROD, connecting
2
112 25P944 PUMP, displacement, tsl cir, .743
1
25P857 PUMP, displacement, tsl cir, .396
1
25P858 PUMP, displacement, tsl cir, .552
1
113 18D010 PUMP, displacement(.396/255.79)
1
245971 PUMP, displacement (.552/356.26)
1
245972 PUMP, displacement (.743/479.22)
1
114 193031 NUT, retaining
2
17A257 NUT, jam, pump
2
193394 NUT, retaining
2
115 176818 PIN, str, hdls
2
183210 PIN, str, hdls
2 2
116 183169 SPRING, retaining
2 2
117 116618 MAGNET
1 1 1
118 127301 SCREW, hxhd, thd cut, 4-40 x .375
2 2 2
119 25R301 SWITCH, reed, assembly
1 1 1
120 187436 LABEL, torque
2
187437 LABEL, torque
2 2
121 192840‡† LABEL, safety, warning, pinch
2 2 2
122 070268 LUBRICANT, grease
1 1 1
123 070386 LUBRICANT, grease, ep
1 1 1
124 15C762 SHIELD, pump rod
2 2
125 118444‡† SCREW, mach, slot hex wash hd
4 4
