Graco Reactor 3 Repair And Parts

Parts
58 3A8501A
18E141, 18E142, 18E145, and 18E146 Parts List
✖ Not shown.
‡ See schematic for heater rod placement.
Ref. Part Description
Qty.
18E141 18E142 18E145 18E146
201 18C669 BLOCK, heater, machined, R3, dual
1 1
201 18C670 BLOCK, heater, machined, r3, single
1 1
202
15H305 FITTING, plug hollow hex 1-3/16 sae
4 4 5 5
203a 18C668 HEATER, immersion, 2400W, 230V
4 2 3 3
203b
‡
16U942 HEATER, immersion, 1380W, 230V
2
204 124132 O-RING
4 4 3 3
205
18B279 SPRING, mixer, heater
4 4 3 3
206
15H306 ADAPTER, thermocouple, 9/16 x 1/8
2 2 1 1
207 120336 O-RING, packing
2 2 1 1
208 121309 FITTING, adapter, sae-orb x jic
2 2 1 1
209
15H304 FITTING, plug 9/16 sae
2 2
210 15M178 HOUSING, rupture disc
2 2 1 1
211
295607 PLUG, hex
2 2 1 1
212 123325 FITTING, compression, 1/8 npt, ss
2 2 1 1
213
124262 SENSOR, rtd, 1kohm, 90deg, 4 pin, tip
2 2 1 1
214 15B137 SWITCH, over temperature
1 1 1 1
215 124131 SCREW, mach, pnh
2 2 2 2
216 121312 FITTING, elbow, sae x jic
2 2 1 1
218✖
070738 LUBRICANT, temporary assembly
1 1 1 1
219
✖ 070408 SEALANT, pipe, sst
1 1 1 1
220
✖ 073019 LUBRICANT, thermal
1 1 1 1
