Graco Reactor 3 - Page 64

Parts
64 3A8501A
25T975, 25T976 Parts List
✖ Not shown.
* Included in 18E252 Inlet Strainer Filter Kit (2-pack) and 18E253 Inlet Strainer Filter Kit (10-pack).
✿ Included in 18E151 Filter Cap O-ring Kit (10-pack).
‡ Included in 18E254 O-ring and Filter Kit (single).
Ref. Part Description
Qty.
25T975 25T976
601
273273 STRAINER, housing, R3, machined
2 2
602
133172 CAP, strainer, R3
2 2
603
15E288 INSERT, manifold
2 2
604*
‡ 132675 FILTER, fluid, 30 mesh
2 2
605
132437 FITTING, elbow, orb-10 x 3/4 npsm
2 2
606
119992 FITTING, pipe, nipple, 3/4 x 3/4 npt
2 2
607
109077 VALVE, ball 3/4 npt
2 2
608
118459 FITTING, union, swivel, 3/4 in.
2 2
609
556424 PLUG, pipe stl rd 7/8-14 sae mg
2 2
610
132438 GAUGE, pressure, 500 psi
2 2
611
18B075 TRANSDUCER, pressure, 1000 psi
2
611
104765 PLUG, pipe, headless, 1/8-27
2
612
132312 SENSOR, temperature
2
612
133173 PLUG, temp sensor
2
613
106555 PACKING, o-ring
2 2
614
100737 PLUG, pipe
2 2
615
133171 INSERT, thread, cap, strainer, R3
2 2
616
✿‡ 132444 O-RING, 125, fx75
2 2
617
107067 PACKING, o-ring
2 2
618
C24035 PACKING, o-ring
2 2
619
✖ 070408 SEALANT, pipe, sst
1 1
620
✖ 070272 LUBRICANT, grease
1 1
621
✖ 070523 ADHESIVE, epoxy, gray
1 1
