Graco Reactor 3 Repair And Parts

Electrical Schematics
74 3A8501A
1 1
2 2
3 3
4 4
D D
C C B B
A A
Primary Heater Connection Detail
RTD
2.4 kW
1 - 2
RTD
2.4 kW
5 - 6
1.4 kW
3 - 4
1.4 kW
7 - 8
7kW
AB
RTD
2.4 kW
1 - 2
RTD
2.4 kW
5 - 6
2.4 kW
3 - 4
2.4 kW
7 - 8
10 kW
AB
15 kW
RTD
2.4 kW
1 - 2
2.4 kW
1 - 2
2.4 kW
3 - 4
X
AB
2.4 kW
5 - 6
2.4 kW
5 - 6
2.4 kW
RTD 7 - 8
X
P8-TCM
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
1
2
3
4
5
6 7 8
AWG 10 / BLK
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
P8-TCM
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
1
2
3
4
5
6 7 8
AWG 12 / BLK
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW )
32-43 Ohm (1.4 kW ) 32-43 Ohm (1.4 kW ) 20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW )
P8-TCM
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
1
2
3
4
5
6 7 8
AWG 12 / BLK
AWG 12 / BLK AWG 12 / BLK AWG 12 / BLK
20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW )
20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW ) 20-25 Ohm (2.4 kW )
26R310, 26R311 26R312, 26R313, 26R320, 26R321
26R322, 26R330, 26R331
26R332, 26R333, 26R340 26R341, 26R342
Models: Models: Models: Graco 18E142 Graco 18E141 Graco 18E145 Graco 18E146
ti40256a
