Parts
62 332144E
24T100, 100-120VAC, Proportioner
24R900, 200-240VAC, Proportioner
Apply sealant to all non-swiveling pipe threads.
Apply sealant to threads of nut cap.
Apply lubricant to thread and axle of cart.
Apply even distribution of thermal grease on bottom of metal
surface of solid state relays.
Torque to 125 in.-lbs (14 N•m).
Torque to 150 in.-lbs (17 N•m).
Assemble nut to finger tight only.
Orient SSR with terminals 1 and 2 towards the top.
Orient fan to flow down and connector plug towards the back.
Orient heater module with fins outwards.
Assemble sensor flush to tank surface.
Install clamp-on ferrite near termination of transducer wires.
See F
IG. 24, page 74.
Install clamp-on ferrite on black and red motor power wires.
See F
IG. 24, page 74.
1
2
3
4
5
6
7
8
9
10
11
12
13
Ref. Part Description
Quantity
24T100,
100-120
VAC
24R900,
200-240
VAC
1 --- CART
11
2 24T950 BRACKET, tank mount
11
3 24T951 BRACKET, crossbar
11
4 24T952 BRACKET, gusset, cart
11
5 24T953 BRACKET, motor mount
11
6 110996 NUT, hex, flange head
18 18
7 101765 GROMMET
33
8 119975 GRIP, vinyl, gray; 1.25 in.
22
9 154636 WASHER, flat
44
10 116411 SPRING, compression
22
11 116477 WASHER, flat, nylon
44
12 116478 WHEEL, pneumatic
22
13 101242 RING, retaining, ext.
22
14 24T954 PROPORTIONER, see page 66
11
15 117493 SCREW, mach, hex washer hd; 1/4-20
44
16 24K985 FAN, cooling, 120 VAC
2
24K986 FAN, cooling, 230 V
2
17 115836 GUARD, finger
22
18 120094 SCREW, pan hd, phil, zinc
88
19 24U009 HEATER, assy; 120V, 1000W; see page 68
1
24T955 HEATER, assy; see page 68
1
20 167002 INSULATOR, heat
22
21 108296 SCREW, mach, hex wash hd
10 10
22 24T960 MANIFOLD, outlet/recirc; see page 71
11
23 24T962 DISPLAY, control; see page 69
11
24 117623 NUT, cap; 3/8-16
44
25 24U005 DIODE, light-emitting,120 V
1
24T970 DIODE, light-emitting, 230 V
1
