Component Identification - Wall Mount
10 311164M
Component Identification - Wall Mount
A Air Inlet, 3/4 npt(f)
B Bleed Type Master Air Valve (required)
C Air Pressure Relief Valve
D Air Filter (hidden)
E Air Pressure Gauge
F Air Regulator Adjustment Knob
GDataTrak
™
location (see page 19; not present on all
models)
J Fluid Drain/Purge Valve (required)
K Fluid Filter
L Grounding Wire (required)
M Lower
N Suction Hose and Tube
P Fluid Outlet
R Optional Fluid Outlet, for second gun
S Packing Nut
T De-Ice Control
U Spray Gun
VHose
F IG . 2: Wall Mount System
M
A
B
E
C,D
F
G
J
K
L
N
P
R
T
TI8413a
V
U
S
