Parts - Dura-Flo Sprayer Packages
311164M 41
Parts - Dura-Flo Sprayer Packages
Model 287979, 287980, and 287981
† Model 287980 only.
★ Model 287981 only.
❄ Not shown.
NOTE: Model 287980 is the only model that
includes a gun and hose.
Ref. Part Description Qty.
601 P23DCD PUMP, Dura-Flo,6500/580 1
★P32DCD PUMP, Dura-Flo, 6500/430 1
602 287884 CART, heavy duty, see pg. 42 1
603 24E013 CONTROL, air, heavy duty cart;
see manual 3A0293
1
604 15K296 SPACER 1
605❄ 120465 SPACER, mounting, threaded 4
606❄ 100133 WASHER, lock 4
610 100088 ELBOW, street, pipe, 90 degrees 1
611 109505 BUSHING 1
612 113864 UNION, swivel,1 1/2 npt 1
613 222914 HOSE, coupled 1
614 109475 ELBOW, pipe, female, 90 degrees 1
615 184475 TUBE, suction 1
616 244524 WIRE, ground assembly w/ clamp 1
617 109213 PACKING, o-ring 1
618 184470 FITTING, outlet 1
629† 103475 FITTING, tee, pipe 1
630† 102646 VALVE, ball 1
631† 235148 HOSE, coupled, 6 ft 1
632† 158256 UNION, swivel 1
633† 240797 HOSE, coupled, 3/8 x 50 1
634† 164856 FITTING, nipple, reducing 1
635† 239984 HOSE, coupled, 1/4 in. x 25 1
636† 189018 SWIVEL, 5800 psi 1
637† 238591 GUN, spray 1
638† 100896 FITTING, bushing, pipe 1
639† 157785 FITTING, swivel 1
640† 165767 TUBE, suction 1
641† 113344 SWIVEL, union assy 1
642† 158491 FITTING, nipple 1
644❄ 100131 NUT, full hex 4
645 15J277 CONTROL, de-ice, assembly 1
