Graco xtreme User Manual

Pump Package Parts
311164M 43
Pump Package Parts
TI8308a
302
302
308
310
309
304 (NXT021)
(lower without
built-in filter)
(lower with built-in filter)
306
307
Pump Package Parts List Page
Pump Packages with L085C# Lowers (80:1 ratio)
pg 44
Pump Packages with L115C# Lowers (35:1, 55:1 ratio)
pg 45
Pump Packages with L145C# and L14AC1 Lowers (31:1, 46:1, 90:1 ratio)
pg 46
Pump Packages with L180C# and L18AC1 Lowers (24:1, 40:1, 70:1 ratio)
pg 47
Pump Packages with L220C# Lowers (21:1, 30:1, 60:1 ratio)
pg 48
Pump Packages with L250C# Lowers (50:1 ratio)
pg 49
Pump Packages with L290C# Lowers (16:1, 25:1, 45:1 ratio)
pg 50
TI8405a
TI8416a
Torque to 25-30 ft-lb
(34-41 N•m)
Torque to 50-60 ft-lb
(68-81 N•m)
Torque to 145-155 ft-lb
(196-210 N•m)
Torque to 27-29 ft-lb
(36-39 N•m)
3
2
2
2
1
3
303
305
311
4
4
1
