Graco xtreme User Manual

Parts - Airless Xtreme Sprayer Packages
30 311164M
Parts - Airless Xtreme Sprayer Packages
The following table lists the major components and part numbers for each airless sprayer package. Refer to Com-
mon Parts, starting on page 35, for parts included with each airless sprayer package.
To determine your specific hopper option and package part number, see the key in Hopper Options, page 34.
Component Parts - All Airless
Sprayer Packages
Sprayer
Package
Reference Number and Description
301 302 303
Pump
(see pg 43)
Lower
(see 311762)
Motor
(see 311238)
X25DH1 P25EC2 L290C2 N34DT0
X25DL1 P25EC2 L290C2 N34DT0
X25DH2 P25EC2 L290C2 N34DT0
X25DL2 P25EC2 L290C2 N34DT0
X25DW2 P25EC4 L290C2 N34DT0
X25DH3 P25DC2 L290C2 N34DN0
X25DL3 P25DC2 L290C2 N34DN0
X25DH4 P25DC2 L290C2 N34DN0
X25DL4 P25DC2 L290C2 N34DN0
X25DW4 P25DC4 L290C2 N34DN0
X25DH5 P25EC2 L290C2 N34DT0
X25DL5 P25EC2 L290C2 N34DT0
X25DH6 P25DC2 L290C2 N34DN0
X25DL6 P25DC2 L290C2 N34DN0
X30DH1 P30EC2 L220C2 N34DT0
X30DL1 P30EC2 L220C2 N34DT0
X30DH2 P30EC2 L220C2 N34DT0
X30DL2 P30EC2 L220C2 N34DT0
X30DW2 P30EC4 L220C2 N34DT0
X30DH3 P30DC2 L220C2 N34DN0
X30DL3 P30DC2 L220C2 N34DN0
X30DH4 P30DC2 L220C2 N34DN0
X30DL4 P30DC2 L220C2 N34DN0
X30DW4 P30DC4 L220C2 N34DN0
X30DH5 P30EC2 L220C2 N34DT0
X30DL5 P30EC2 L220C2 N34DT0
X30DH6 P30DC2 L220C2 N34DN0
X30DL6 P30DC2 L220C2 N34DN0
X35DH1 P35EC2 L115C2 N22DT0
X35DL1 P35EC2 L115C2 N22DT0
X35DH2 P35EC2 L115C2 N22DT0
X35DL2 P35EC2 L115C2 N22DT0
X35DW2 P35EC4 L115C2 N22DT0
X35DH3 P35DC2 L115C2 N22DN0
X35DL3 P35DC2 L115C2 N22DN0
X35DH4 P35DC2 L115C2 N22DN0
X35DL4 P35DC2 L115C2 N22DN0
X35DW4 P35DC4 L115C2 N22DN0
X35DH5 P35EC2 L115C2 N22DT0
X35DL5 P35EC2 L115C2 N22DT0
X35DH6 P35DC2 L115C2 N22DN0
X35DL6 P35DC2 L115C2 N22DN0
X40DH1 P40EC2 L180C2 N34DT0
X40DL1 P40EC2 L180C2 N34DT0
X40DH2 P40EC2 L180C2 N34DT0
X40DL2 P40EC2 L180C2 N34DT0
X40DW2 P40EC4 L180C2 N34DT0
X40DH3 P40DC2 L180C2 N34DN0
Sprayer
Package
Reference Number and Description
301 302 303
Pump
(see pg 43)
Lower
(see 311762)
Motor
(see 311238)
