Graco xtreme User Manual

Parts - Airless Xtreme Sprayer Packages
34 311164M
Hopper Options
If your sprayer package includes a hopper, use the fol-
lowing table to determine the specific hopper option. For
example, X60DH5 indicates the airless sprayer package
includes a hopper, gun, hose, and DataTrak.
Motor Key
X90LH1 P90MC2 L145C2 N65LT0
X90LL1 P90MC2 L145C2 N65LT0
X90LH2 P90MC2 L145C2 N65LT0
X90LL2 P90MC2 L145C2 N65LT0
X90LW2 P90MC4 L145C2 N65LT0
X90LH3 P90LC2 L145C2 N65LN0
X90LL3 P90LC2 L145C2 N65LN0
X90LH4 P90LC2 L145C2 N65LN0
X90LL4 P90LC2 L145C2 N65LN0
X90LW4 P90LC4 L145C2 N65LN0
X90LH5 P90MC2 L145C2 N65LT0
X90LL5 P90MC2 L145C2 N65LT0
X90LH6 P90LC2 L145C2 N65LN0
X90LL6 P90LC2 L145C2 N65LN0
Sprayer
Package
Reference Number and Description
301 302 303
Pump
(see pg 43)
Lower
(see 311762)
Motor
(see 311238)
Digit 6 Option
5 Hopper Package; complete package
with DataTrak
6 Hopper Package; complete package
without DataTrak
7 Lower without integrated fluid filter
First Digit
Motor N (NXT Air Motor)
Second and
Third Digits
cc per stroke 65 = 6500
34 = 3400
22 = 2200
Fourth Digit
Exhaust Type D = De-icing
L = Low noise
R = Remote
Fifth Digit
Data
Monitoring
N = None
T = DataTrak
H = High level linear sensor
Sixth Digit
Unassigned 0 = Non assigned
