Mounting Hole Diagram
54 311164M
Mounting Hole Diagram
Wall Mount Bracket
TI8614a
9.0 in.
(228.6 mm)
1.6 in.
(41.4 mm)
12.4 in.
(314.3 mm)
1.0 in.
(25.4 mm)
7.4 in.
(187.3 mm)
5.3 in.
(133.4 mm)
14.5 in.
(368.3 mm)
17.8 in.
(450.9 mm)
2.0 in.
(50.8 mm)
5.4 in.
(136.5 mm)
7/16 in. (11 mm)
diameter holes for
mounting to wall
1/2 in. (12.7 mm) diameter
holes for mounting to stand
