Parts - Airless Xtreme Sprayer Packages
36 311164M
Airless Sprayers with Hopper Packages
Hopper kit is shown on page 26.
◆ X35*** models only.
❄ Not shown.
Wall Mount Packages
◆ X35*** models only.
❄ Not shown.
Wall Mount Package 287978
Ref. Part Description Qty.
2CART 1
287884 Heavy duty (H); see pg. 39
287919 Light weight (L); see pg. 39
5 116401 ADAPTER, elbow 1
6 116402 ADAPTER, quick connect 1
7 244524 WIRE, ground assy. w/ clamp 1
11❄ 100101 SCREW, mounting, cap, hex head 4
12❄ 100133 WASHER, lock 4
14 AIR CONTROLS 1
24E013 CONTROL, air, heavy duty cart;
see manual 3A0293
24E025 CONTROL, air, light duty cart;
see manual 3A0293
101 GUN, spray 1
XTR504 XTR5 spray gun for models with
25:1 - 50:1 ratio only
XTR704 XTR7 spray gun for models with
55:1 - 90:1 ratio only
102 HOSE, fluid; nylon; 1/4 in. ID, 1/4
npsm(fbe); 6 ft.
1
H42506 Models with 25:1 - 45:1 ratio
H52506 Models with 46:1 - 55:1 ratio
H72506 Models with 60:1 - 90:1 ratio
103 HOSE, fluid; nylon, 3/8 in. ID; 3/8
npsm(fbe); 50 ft.
1
H43850 Models with 25:1 - 45:1 ratio
H53850 Models with 46:1 - 55:1 ratio
H73850 Models with 60:1 - 90:1 ratio
104 164856 FITTING, NIPPLE, reducing;
3/8 x 1/4 npt(m)
1
108 162505 FITTING, union, swivel;
1/2 in. F x 3/8 in. M
1
109 288347 HOPPER, kit (includes a - n) 1
109a HOPPER, fluid 1
109b BRACKET, hopper 1
109c BRACKET, hanger, hopper 1
109d VALVE, ball 1
109e FITTING, connection, hopper 1
109f SCREW, cap, hex head 2
109g NUT, hex, flanged 2
109m NUT, wing 1
109n FITTING, NIPPLE, reducing 1
110◆ 247312 PLATE, adapter kit (includes a-b)
for NXT 2200 Air Motors
1
110a❄ NUT, lock 4
110b❄ PLATE, adapter 1
Ref. Part Description Qty.
203 197682 TUBE, suction 1
204 247302 HOSE, suction,1 in.,
NPT x quick connect; 10 ft.
1
205 116401 ADAPTER, elbow 1
206 116402 ADAPTER, quick connect 1
207 244524 WIRE, ground assy. w/clamp 1
208 100101 SCREW, mounting, cap, hex head 4
209 100133 WASHER, lock 4
210 181072 INLET, strainer 1
211 245136 TUBE, intake extension
(includes 211a-211b)
1
211a COUPLING, pipe, 1 in. 1
211b TUBE, intake 1
213 255143 BRACKET (W), mounting
(includes 208-209)
1
214◆ 247312 PLATE, adapter kit (includes
214a-214b) for NXT 2200 Air
Motors
1
214a❄ NUT, lock 4
214b❄ PLATE, adapter 1
Ref. Part Description Qty.
203 197682 TUBE, suction 1
204 247302 HOSE, suction,1 in.,
NPT x quick connect; 10 ft.
1
205 116401 ADAPTER, elbow 1
206 116402 ADAPTER, quick connect 1
207 244524 WIRE, ground assy. w/clamp 1
208 100101 SCREW, mounting, cap, hex head 4
209 100133 WASHER, lock 4
210 181072 INLET, strainer 1
211 245136 TUBE, intake extension
(includes 211a-211b)
1
211a COUPLING, pipe, 1 in. 1
211b TUBE, intake 1
213 255143 BRACKET (W), mounting
(includes 208-209)
1
214 218029 FILTER, fluid 1
215 100509 PLUG, pipe 2
216 150286 ADAPTER, 2 x 3/8-18 NPT 1
217 210658 VALVE, ball 1
218 157705 UNION, swivel, 3/8-18 npsm x
1/4-18 NPT
1
219 155665 UNION, adapter, 3/8-18 npsm x
3/8-18 NPT
1
220 161800 ADAPTER, 3/4 x 3/8 mbe 1
301 P40MC3 PUMP 1
NOTE: Wall Mount Package parts are shown on
page 29.
