Dimensions
311164M 53
Weights
Sprayer (Cart Mounted)
Packages
❄ Add 10 lbs (4.54 kg) for built-in filter. Add 5 lbs (2.27 kg)
for air controls.
NOTE: Weights are approximate and do not
include hoses or guns.
Ratio
Heavy Duty Cart
lbs (kg)
Light Weight Cart
lbs (kg)
25:1 228.4 (103.6) 196.1 (89.0)
30:1 227.4 (103.1) 195.1 (88.5)
35:1 209.9 (95.2) 177.6 (80.6)
40:1 223.4 (101.3) 191.1 (86.7)
45:1 247.4 (112.2) 215.1 (97.6)
46:1 223.4 (101.3) 191.1 (86.7)
50:1 246.4 (111.8) 214.1 (97.1)
55:1 211.4 (95.9) 179.1 (81.2)
60:1 246.4 (111.8) 214.1 (97.1)
70:1 242.4 (109.9) 210.1 (95.3)
80:1 211.4 (95.9) 179.1 (81.2)
90:1 242.4 (109.9) 210.1 (95.3)
Wall Mount
Packages
Pump Assembly
Packages
Ratio lbs (kg) Ratio
No Filter, No Air
Controls❄
lbs (kg)
25:1 159.0 (72.1) 16:1 99.4 (45.1)
30:1 158.0 (71.7) 21:1 98.4 (44.6)
35:1 140.5 (63.7) 24:1 94.4 (42.8)
40:1 154.0 (69.9) 25:1 103.4 (46.9)
45:1 178.0 (80.8) 30:1 102.4 (46.4)
46:1 154.0 (69.9) 31:1 94.4 (42.8)
50:1 177.0 (80.3) 35:1 84.4 (38.3)
55:1 142.0 (64.4) 40:1 98.4 (44.6)
60:1 177.0 (80.3) 45:1 122.4 (55.5)
70:1 173.0 (78.5) 46:1 98.4 (44.6)
80:1 142.0 (64.4) 50:1 121.4 (55.1)
90:1 173.0 (78.5) 55:1 88.4 (40.1)
60:1 121.4 (55.1)
70:1 117.4 (53.3)
80:1 88.4 (40.1)
90:1 117.4 (53.3)
