Pump Packages with L145C# and L14AC1 Lowers (31:1, 46:1, 90:1 ratio)
46 311164M
Pump Packages with L145C# and L14AC1 Lowers
(31:1, 46:1, 90:1 ratio)
* NXT021 Air Control assemblies for P90xxx model pumps are equipped with safety relief valve 116643. Reorder this part number.
Pump
Package
Reference Number and Description
302 303 *304 305 306 307 308 309 310 311
Lower
(see 311762)
Built-in
Filter
Motor
(see 311238)
Air
Control
(NXT021)
(see
311239)
Coupling,
assy.
Rod,
tie
Cover,
coupler
Nut,
lock
Clip,
hairpin w/
lanyard
Adapter,
rod
De-ice
Control
Knob
P31LC1 L14AC1 N22LN0
244819
257150 197340 101712 244820 15H392 NXT112
(5-pack)
P31MC1 L14AC1 N22LT0
P31DC1 L14AC1 N22DN0
P31EC1 L14AC1 N22DT0
P46DC1 L145C1 N34DN0
P46DC2 L145C2
N34DN0
P46DC3 L145C1 N34DN0
P46DC4 L145C2
N34DN0
P46EC1 L145C1 N34DT0
P46EC2 L145C2
N34DT0
P46EC3 L145C1 N34DT0
P46EC4 L145C2
N34DT0
P46LC1 L145C1 N34LN0
P46LC2 L145C2
N34LN0
P46LC3 L145C1 N34LN0
P46LC4 L145C2
N34LN0
P46MC1 L145C1 N34LT0
P46MC2 L145C2
N34LT0
P46MC3 L145C1 N34LT0
P46MC4 L145C2
N34LT0
P90DC1 L145C1 N65DN0
P90DC2 L145C2
N65DN0
P90DC3 L145C1 N65DN0
P90DC4 L145C2
N65DN0
P90EC1 L145C1 N65DT0
P90EC2 L145C2
N65DT0
P90EC3 L145C1 N65DT0
P90EC4 L145C2
N65DT0
P90LC1 L145C1 N65LN0
P90LC2 L145C2
N65LN0
P90LC3 L145C1 N65LN0
P90LC4 L145C2
N65LN0
P90MC1 L145C1 N65LT0
P90MC2 L145C2
N65LT0
P90MC3 L145C1 N65LT0
P90MC4 L145C2
N65LT0
Qty. 1 1113131 11
