Pump Packages with L290C# Lowers (16:1, 25:1, 45:1 ratio)
50 311164M
Pump Packages with L290C# Lowers (16:1, 25:1, 45:1 ratio)
Pump
Package
Reference Number and Description
302 303 304 305 306 307 308 309 310 311
Lower
(see 311762)
Built-in
Filter
Motor
(see 311238)
Air
Control
(NXT021)
(see
311239)
Coupling,
assy.
Rod,
tie
Cover,
coupler
Nut,
lock
Clip,
hairpin w/
lanyard
Adapter,
rod
De-ice
Control
Knob
P16DC1 L29AC1 N22DN0
244819
257150 197340 101712 244820 15H392 NXT112
(5-pack)
P16EC1 L29AC1 N22DT0
P16LC1 L29AC1 N22LN0
P16MC1 L29AC1 N22LT0
P25DC1 L290C1 N34DN0
P25DC2 L290C2
N34DN0
P25DC3 L290C1 N34DN0
P25DC4 L290C2
N34DN0
P25EC1 L290C1 N34DT0
P25EC2 L290C2
N34DT0
P25EC3 L290C1 N34DT0
P25EC4 L290C2
N34DT0
P25LC1 L290C1 N34LN0
P25LC2 L290C2
N34LN0
P25LC3 L290C1 N34LN0
P25LC4 L290C2
N34LN0
P25MC1 L290C1 N34LT0
P25MC2 L290C2
N34LT0
P25MC3 L290C1 N34LT0
P25MC4 L290C2
N34LT0
P45DC1 L290C1 N65DN0
P45DC2 L290C2
N65DN0
P45DC3 L290C1 N65DN0
P45DC4 L290C2
N65DN0
P45EC1 L290C1 N65DT0
P45EC2 L290C2
N65DT0
P45EC3 L290C1 N65DT0
P45EC4 L290C2
N65DT0
P45LC1 L290C1 N65LN0
P45LC2 L290C2
N65LN0
P45LC3 L290C1 N65LN0
P45LC4 L290C2
N65LN0
P45MC1 L290C1 N65LT0
P45MC2 L290C2
N65LT0
P45MC3 L290C1 N65LT0
P45MC4 L290C2
N65LT0
Qty. 1 1113131 11
