Grandstream Networks GWN7602 User Manual

P a g e | 14
GWN7602 User Manual
Version 1.0.15.20
PRODUCT OVERVIEW
Technical Specifications
Table 1: GWN7602 Technical Specifications
Wi-Fi Standards
IEEE 802.11 a/b/g/n/ac
Antennas
2 dual band internal antennas.
Antenna 1 - 2.4GHz: gain 3.0dBi, 5GHz: gain 3.5dBi
Antenna 2 - 2.4GHz: gain 3.5dBi, 5GHz: gain 3.0dBi
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 867Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5Mbps to 300Mbps
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance
between devices, radio interference in the operating environment and mix of devices in the network.
Frequency Bands
2.4 GHz Radio: 2412 – 2484 GHz
5 GHz Radio: 5150-5250 MHz, 5250-5350 MHz, 5470-5725 MHz, 5725-5850 MHz
Channel Bandwidth
2.4G: 20 and 40 MHz
5G: 20, 40, 80 MHz
Wi-Fi and System
Security
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise.
MIMO
4x4:4 2.4GHz (MIMO)
4x4:4 5GHz (MU-MIMO)
Coverage Range
Up to 100 meters
*coverage range can vary based on environment
Maximum TX Power
2.4G: 21 dBm
5G: 21 dBm
*Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity
2.4G
802.11b:-96dBm@1Mbps,-88dBm@11Mbps;802.11g:-93dBm@6Mbps, -
76dm@54Mbps; 802.11n20MHz:-92dBm@MCS0,-
73dBm@MCS7;802.11n40MHz: -88.5dBm@MCS0,-71dBm@MCS7
