Grandstream Networks GWN7602 User Manual

P a g e | 17
GWN7602 User Manual
Version 1.0.15.20
Table 2: GWN7602 AP Ports Description
Port
Description
DC12V
Power adapter connector (12V, 2A)
PoE
Ethernet RJ45 port (10/100/1000Mbps) supporting PoE/PoE+.
LAN1
1x 10/100M Ethernet port.
LAN2/LAN3
2x 10/100M Ethernet ports with PSE.
RESET
Factory reset pinhole.
Press for 7 seconds to reset factory default settings.
Power and Connect GWN7602 Access Point
The GWN7602 can be powered either using the right PSU (DC12V, 2A) or using a PoE/PoE+ switch:
- Option A: Power Adapter to AC outlet.
- Option B: RJ45 Ethernet Cable to PoE/PoE+ switch
Figure 2: Connecting GWN7602
Warranty
If the GWN7602 Wireless Access Point was purchased from a reseller, please contact the company where
the device was purchased for replacement, repair or refund.
If the device was purchased directly from Grandstream, contact our Technical Support Team for an RMA
(Return Materials Authorization) number before the product is returned. Grandstream reserves the right to
remedy warranty policy without prior notification.
