GWN7602 User Manual
Version 1.0.15.20
Filtering Options
Custom Filter
Check this option when adding custom filtering rule. When selected, the default
filtering options will be hidden (Source Port, Destination Port...etc).
Custom Filtering
Rule
Configures a filter expression in which traffic should be captured，for example：
icmp and host 8.8.8.8. Once configured, then you need to click on Validate.
Source Port
Set the Source Port to filter capture traffic coming from the defined source port.
Destination Port
Set the Destination Port to filter capture traffic coming from the defined port.
Source IP
Set the Source IP to filter capture traffic coming from the defined source IP.
Destination IP
Set Destination IP to filter capture traffic coming from the defined destination IP.
Protocol
Choose ALL or a specific protocol to capture (IP, ARP, RARP, TCP, UDP, ICMP)
Filtering Options
Logic
Choose the filtering logic between all filter options to either “And” or “Or” when
capturing traffic.
Device
Select the device from which you want to list the captured file.
• Click on to start capturing on a certain device plugged to the USB port.
• Click on to stop the capture.
Click on to show the captured files on a chosen device, users could check the capture
files details.
• Click on to delete all files.
• Click on next to a capture file to download it on a local folder.
• Click on to delete the corresponding capture file.
