Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 82 of 117
messages in decimal pattern. This value is used for IP Precedence,
Diff-Serv or MPLS. The default setting is 48 which is equivalent to the
DSCP name constant CS6.
Layer 3 QoS for Audio
It is used to define the Layer 3 packet’s QoS parameter for RTP
messages in decimal pattern. This value is used for IP Precedence,
Diff-Serv or MPLS. The default setting is 48 which is equivalent to the
DSCP name constant CS6.
Layer 3 QoS for Video
It is used to define the Layer 3 packet’s QoS parameters for H.264
messages in decimal pattern. This value is used for IP Precedence,
Diff-Serv or MPLS. The default setting is 48 which is equivalent to the
DSCP name constant CS6.
Layer 2 QoS 802.1Q/VLAN
Tag (Ethernet)
It is used to assign the VLAN Tag of the Layer 2 QoS packets for
Ethernet. The Default value is 0.
Layer 2 QoS 802.1p Priority
Value (Ethernet)
It is used to assign the priority value of the Layer 2 QoS packets for
Ethernet. The Default value is 0.
Layer 2 QoS 802.1Q/VLAN
Tag (Wi-Fi)
It is used to assign the VLAN Tag of the Layer 2 QoS packets for Wi-
Fi. The Default value is 0.
Layer 2 QoS 802.1p Priority
Value (Wi-Fi)
It is used to assign the priority value of the Layer 2 QoS packets for
Wi-Fi. The Default value is 0.
PC Port VLAN Tag
It is used to define the VLAN Identifier of the Layer 2 frame for PC port.
This tags the VLAN tag value on the target address received from the
LAN port of the phone then sends the value to the device connected
to the PC port.
Note:
VLAN tag value on the device connected to the PC port should be the
same as the VLAN tag value assigned to the PC port here.
PC Port Priority Value
It is used to define the Priority Code Point within a Layer 2 frame
header for PC port.
PC Port Mode
It is used to enable and define the PC port mode. If it is set to
“Mirrored”, the traffic in the LAN port will go through PC port as well
and packets can be captured by connecting a PC to the PC port. The
default setting is “Enabled”.
User-Agent
It is used to configure the User Agent URI to download phonebook and
screensaver files.
802.1x mode
It is used to enable and select the 802.1x mode for the phone system.
The supported 802.1x modes are :
 EAP-MD5
 EAP-TLS
