Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 95 of 117
Download Interval
It is used to set if allow and how often the phone system to send the
request to the server to download the phonebook file.
It can be selected from the dropdown list:
 None
 2 Hour
 4 Hour
 6 Hour
 8 Hour
 12 Hour
Note:
For more information on XML Based Downloadable Phonebook on GXV3240, please refer to the GXV3240
XML Phonebook Guide in the following link:
http://www.grandstream.com/products/gxv_series/gxv3240/documents/gxv3240_xml_phonebook_guide.p
df
MAINTENANCE/LDAP BOOK
Connection Mode
It is used to select which protocol will be used for LDAP searching,
LDAP or LDAPS.
Server Address
It is used to configure the URI of the LDAP (Lightweight Directory
Access Protocol) server.
Port
It is used to configure the LDAP server port. The default LDAP port
number is 389.
Base DN
It is used to configure the LDAP search base. This is the location in the
directory where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
It is used to configure the bind "Username" for querying LDAP servers.
Some LDAP servers allow anonymous binds in which case the setting
can be left blank.
Password
It is used to configure the bind "Password" for querying LDAP servers.
The field can be left blank if the LDAP server allows anonymous binds.
LDAP Name Attributes
It is used to configure the "name" attributes of each record which are
returned in the LDAP search result. This field allows the users to
