Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 79 of 117
ADVANCED SETTINGS/MPK EXT SETTINGS (FOR GXV3240 EXT BOARD 1/2/3/4)
Key Mode
It is used to assign a function to the Multi-Purpose Key in the MPK app
The key mode options are:
 Speed Dial
Press to dial the extension configured in UserID field.
 Busy Lamp Field (BLF)
Monitor the extension status as configured in UserID field.
 Call Transfer
Transfer the current active call to the extension configured in
UserID field.
 Call Intercom
Intercom/paging to the extension configured in UserID field.
 Speed Dial via Active Account
Similar to Speed Dial but it will dial based on the current active
account. For example, if the phone is offhook and account 2 is
active, it will call the configured extension using account 2.
 Dial DTMF
Dial the DTMF digits filled in UserID field during a call.
 Eventlist BLF
This option is similar to the BLF option, but in this case, the PBX
collects the information from the phones, and sends it out in one
single notify message. PBX server has to support this feature.
 Call Park
Configure the call park feature code to park or pick up the call.
 Multicast Paging
Configure the IP address and port for establish a multicast paging
call.
Account
It is used to selects the SIP Account assigned with the multi-purpose
keys.
Name
It is used to configure the display name for the multi-purpose key.
UserID
It is used to configure the UserID for the corresponding multi-purpose
key mode.
MPK ID
It is used to identify the "MPK ID x" for "MPK x". The default number is
from 1-160 for 160 MPKs in 4 GXV3240EXT boards.
For example, if MPK 1's MPK ID is changed from 1 to 5, users will see
the configuration saved on MPK 5.
Display Format
It is used to set the display format for the multi-purpose keys. Users
could select display "Name", "UserID", or "Name (UserID)". "Name" is
the one saved in phone contacts. The default setting is "Name".
