Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 81 of 117
MAINTENANCE PAGE DEFINITION
MAINTENANCE/NETWORK SETTINGS
Address Type
It is used to configure the appropriate network settings on the phone.
Users could select from "DHCP", "Static IP" or "PPPoE"(Point-to-point
Protocol over Ethernet). By default, it is set to "DHCP".
Enable DHCP VLAN
It is used to configure whether to enable DHCP VLAN function. Once
enabled, the device will use DHCP option 132 (802.1Q VLAN ID) and
DHCP option 133 (QOS priority level) sent by DHCP server to set local
network. The default setting is "No".
DHCP Host name (Option 12)
It is used to configure the name of the client in the DHCP request. It is
optional but may be required by some Internet Service Providers.
DHCP Vendor Class ID
(Option 60)
It is used to configure the vendor class ID header in the DHCP request.
The default setting is Grandstream GXV3240.
IP Address
It is used to configure the phone’s static IP address if the static IP is
used.
Subnet Mask
It is used to configure the network’s subnet mask if the static IP is used.
Default Gateway
It is used to configure the network’s gateway address if the static IP is
used.
DNS Server 1
It is used to configure the primary DNS IP address if the static IP is
used.
DNS Server 2
It is used to configure the secondary DNS IP address if the static IP is
used.
PPPoE Account ID
It is used to configure the PPPoE account ID if the PPPoE is used.
PPPoE Password
It is used to configure the PPPoE password if the PPPoE is used.
Alternate DNS Server
It is used to configure the alternate DNS IP address to failover during
the default DNS server’s outage.
Second Alternate DNS Server
It is used to configure the secondary alternate DNS IP address to
failover during both the default DNS server and alternate DNS server’s
outage.
Show IP Address On Account
Widget
This is used to configure whether to show IP address of the phone on
desktop account widget. The default setting is "Yes".
Enable LLDP
It is used to enable the LLDP (Link Layer Discovery Protocol) feature
on the phone system. If it is set to “Yes”, the phone system will
broadcast LLDP PDU to advertise its identity and capabilities and
receive same from a physical adjacent layer 2 peer. The default setting
is “Yes”.
Layer 3 QoS for SIP
It is used to define the Layer 3 packet’s QoS parameter for SIP
