Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 43 of 117
DEFINITIONS
This section describes the options in the GXV3240 Web GUI. As mentioned, you can log in as an
administrator or an end user.
 Status: Displays the Account Status, Network Status, and System Info of the phone.
 Account (1-6): To configure each of the SIP accounts.
 Advanced Settings: To configure General Settings, Call Features, Video Settings, Tone Generator
and MPK Settings for MPK App as well as GXV3240 extension board.
 Maintenance: To configure Network Settings, Wi-Fi Settings, Time Settings, Web/SSH Access,
Upgrade, Syslog, Logcat, Debug, Language, TR-069, Contacts, LDAP Book and Device Manager.
The following table shows the web pages accessible by end user and administrator respectively.
Table 4: GXV3240 Web Access
User Type
Username
Default Password
Accessible Web Pages
Administrator
admin
admin
All pages
End User
user
123
 Status: Account Status, Network Status,
System Info.
 Advanced Settings: Tone Generator, MPK
General Settings, MPK LCD Settings, MPK EXT
Settings.
 Maintenance: Network Settings, Wi-Fi Settings,
Time Settings, Web/SSH Access, Logcat,
Debug, Language, Contacts, LDAP Book,
Broadsoft, Device Manager.
TOOLBAR
The web UI tool bar is on the upper right corner of the web UI page.
Figure 14: GXV3240 Web UI Tool Bar
 Theme: Select the web UI style to display the web page.
