Grandstream Networks GXV3240 Administration Guide

Firmware Version 1.0.3.46
GXV3240 Administration Guide
Page 94 of 117
one. Otherwise, the phone system will save both contact entries.
The default setting is "No".
Local File
It is used to upload the contact files from PC to the phone system.
Download
Clear The Old List
It is used to set if the phone system will delete the previous contacts
when a new contact file is downloaded. If set to "Yes", the previous
contacts will be removed. The default setting is "No".
Replace Duplicate Items
It is used to set if the phone system will keep the original contact
entries when duplicated contact entries are included in the contact file.
If set to "Yes", the phone will replace the original entries to the new
one. Otherwise, the phone system will save both contact entries.
The default setting is "No".
Download Mode
It is used to enable the phone system to download phonebook file and
select the server and protocol to download the phonebook file. It can
be selected from TFTP, HTTP, and HTTPS. The default setting is
“OFF”.
File Encoding
It is used to select the encoding format for phonebook file download.
It can be selected from the dropdown list:
 UTF-8
 GBK
 UTF-16
 UTF-32
 Big5
 Big5-HKSCS
 Shift-JIS
 ISO8859-1
 ISO8859-15
 Windows-1251
 EUC-KR
The default setting is UTF-8.
Download Server
It is used to configure the server URI to download the phonebook file.
The phone system will send request to the server to download the
phonebook file with filename phonebook.xml.
HTTP/HTTPS User Name
This is used to configure the user name for the HTTP/HTTPS server
to download the phonebook file.
HTTP/HTTPS Password
This is used to configure the password for the HTTP/HTTPS server to
download the phonebook file.
Download Now
Click on the "Download" button to start downloading the XML
phonebook to the phone immediately.
