GXV3350 Administration Guide
Version 1.0.3.27
P a g e | 66
Network Settings Page Definitions
Network Settings/Ethernet Settings
Ethernet Settings
IP Mode
If IPv4 is selected, the phone will be using IPv4 addressing, otherwise, it
will be using IPv6 addressing. Default is Prefer IPv4.
Different Networks for
Data and VoIP Calls
Configures whether to set up different networks for the phone data and the
call. If set to "Yes", you need to configure the data network and VoIP
network respectively.
IPv4
IPv4 Address Type
Configures the appropriate network settings on the phone.
Users could select from "DHCP", "Static IP" or "PPPoE"(Point-to-point
Protocol over Ethernet). By default, it is set to "DHCP".
DHCP VLAN Override
Selects the DHCP Option VLAN mode. When set to "DHCP Option 132
and DHCP option 133", the phone will get DHCP option 132 and 133 as
VLAN ID and VLAN priority. When set to "Encapsulated in DHCP Option
43", the phone will get values from Option 43 which encapsulate VLAN ID
and VLAN priority.
Note: Please make sure the "Allow DHCP Option 43 and Option 66 to
Override Server" setting under maintenanceupgrade is checked. The
default setting is " Encapsulated in DHCP Option 43 ".
DHCP Host name
(Option 12)
Sets the name of the client in the DHCP request. It is optional but may be
required by some Internet Service Providers.
Vendor Class ID
(Option 60)
Configures the vendor class ID header in the DHCP request.
The default setting is Grandstream GXV3380.
IP Address
Defines the phone’s static IP address if the static IP is used.
Subnet Mask
Determines the network’s subnet mask if the static IP is used.
Default Gateway
Defines the network’s gateway address if the static IP is used.
DNS Server 1
Configures the primary DNS IP address if the static IP is used.
DNS Server 2
Configures the secondary DNS IP address if the static IP is used.
PPPoE Account ID
Configures the PPPoE account ID if the PPPoE is used.
PPPoE Password
Sets the PPPoE password if the PPPoE is used.
Layer 2 QoS
802.1Q/VLAN Tag
(Ethernet)
Assigns the VLAN Tag of the Layer 2 QoS packets for Ethernet.
The Default value is 0.
Note: When Different Networks for Data and VoIP Calls set to Yes, then
this option will be applied for Data.
Layer 2 QoS 802.1p
Priority Value (Ethernet)
Assigns the priority value of the Layer 2 QoS packets for Ethernet.
The Default value is 0.
