Grandstream Networks GXV3350 Administration Guide

GXV3350 Administration Guide
Version 1.0.3.27
P a g e | 88
displayed on 4 extension boards.
Sync Backlight with
LCD
Configures whether to synchronize the backlight with LCD. If set to "Yes",
the backlight will turn off when LCD is in idle.
Proxy Prefix
Account
Displays account name if configured, otherwise, displays “Account X”
where X is the account number.
BLF Call-pick Prefix
Configures the prefix prepended to the BLF extension if the phone answers
a call to the monitored party by the BLF key. Default setting is ** for each
account.
Event List URI
Determines the event list BLF URI on the phone to monitor the extensions
in the list with MPK keys. This feature is based on BroadSoft standard. It
requires filling in the BLF ID to the box.
For example, if the server provides the URI: BLF123@myserver.com, this
field should be filled with BLF123. Then the monitored extensions will be
populated in the MPK app or Extension Board (if supported).
Force BLF Call-pickup
by Prefix
Uses the prefix for BLF Call-pickup. The default setting is “No”.
System Application/Contacts
General Settings
Sort Phonebook by
Sets which part of name, first name or last name, will be sorted in
alphabetical order to display.
Default Contacts Tab
Controls the behaviors of the phonebook key. It could be set to:
 Default
 LDAP Search
 Local Phonebook
 Local Group
 Broadsoft Phonebook
 Favorites.
The default setting is “Default”, which set the phonebook key to the
Contacts menu.
Emergency Call
Numbers
Configures the emergency contact in logout mode. If the system is logout,
guest users can dial the configured emergency contacts.
Input the number in the input box and click "Add" to add the number to the
contacts list. To delete the existing ICE number, select the number in the
contacts list and click "Delete".
Import/Export Contacts
Import

Grandstream Networks GXV3350 Specifications

General

Brand	Grandstream Networks
Model	GXV3350
Category	Telephone
Language	English
