Grandstream Networks GXW45 Series User Manual

Gateway
Configure the IPv4 or IPv6 gateway address so that the GXW450X can reach the destination via this gateway. The gateway address
optional.
Example:
192.168.40.5 or 2001:740:D::1
Interface Specify the network interface on the GXW450X to reach the destination using the static route.
Table 9: GXW450X Network Settings 🡪 Static Routes
Port Forwarding
The GXW450X network interface supports router functions which provide users the ability to do port forwarding. If the GXW450X is set to “Route”
Web GUI🡪System Settings🡪Network Settings🡪Basic Settings: Method, port forwarding is available for configuration.
The port forwarding configuration is under the Web GUI🡪System Settings🡪Network Settings🡪Port Forwarding page. Please see the related settin
the table below.
WAN
Port
Specify the WAN port number or a range of WAN ports. An unlimited number of ports can be configured.
Note:
When it is set to a range, the WAN port, and LAN port must be configured with the same range, such as WAN port: 1000-1005 and LA
port: 1000-1005, and access from the WAN port will be forwarded to the LAN port with the same port number, for example, WAN port
will be port forwarding to LAN port 1000.
LAN IP Specify the LAN IP address.
LAN
Port
Specify the LAN port number or a range of LAN ports.
Note:
When it is set to a range, the WAN port, and LAN port must be configured with the same range, such as WAN port: 1000-1005 and LA
port: 1000-1005, and access from the WAN port will be forwarded to the LAN port with the same port number, for example, WAN port
will be port forwarding to LAN port 1000.
Protoc
ol
Type
Select protocol type “UDP Only”, “TCP Only” or “TCP/UDP” for the forwarding in the selected port. The default setting is “UDP Only”.
Table 10: GXW450X System Settings 🡪 Network Settings 🡪 Port Forwarding
OpenVPN®
OpenVPN® settings allow the users to configure GXW450X to use VPN features, the following table gives details about the various options in ord
configure the GXW450X as OpenVPN Client.
OpenVPN® Enable Enable / Disable the OpenVPN® feature. The default is “Disabled”.
Configuration Method
Select the OpenVPN® configuration method.
Manual Configuration.
Upload Configuration File.
If “Configuration Method” is set to
“Manual Configuration”
OpenVPN® Server Address
Configures the hostname/IP and port of the server. For example, “192.168.1.2:22” or
“2001:0DB8:0000:0000:0000:0000:1428:0000”.
