Figure 23: GXW450X using 802.1X EAP-MD5
The following table shows the configuration parameters for 802.1X on GXW450X. Identity and MD5 password are required for authentication, whic
should be provided by the network administrator obtained from the RADIUS server. If “EAP-TLS” or “EAP-PEAPv0/MSCHAPv2” is used as the 802.1
mode, users will also need to upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated from the RADIUS server.
802.1X Mode
Select 802.1X mode. The default setting is “Disable”. The supported 802.1X mode is:
EAP-MD5
EAP-TLS
EAP-PEAPv0/MSCHAPv2
Identity Enter 802.1X mode Identity information.
MD5 Password Enter 802.1X mode MD5 password information.
802.1X CA Certificate Upload 802.1X CA certificate. This file will be renamed as “8021x_ca_cert” automatically.
802.1X Client
Certificate
Upload 802.1X client certificate with both certificate and private key. This file will be renamed as “8021x_client_cert”
automatically.
Table 8: GXW450X Network Settings
🡪
802.1X
Static Routes
The GXW450X provides users static routing capability that allows the device to use manually configured routes, rather than information only from
dynamic routing or gateway configured in the GXW450X Web GUI🡪System Settings🡪Network Settings🡪Basic Settings to forward traffic. It ca
used to define a route when no other routes are available or necessary.
Click on to create a new IPv4 static route or click on to create a new IPv6 static route. T
configuration parameters are listed in the table below.
Once added, users can select to edit the static route.
Select to delete the static route.
Destinatio
n
Configure the destination IPv4 address or the destination IPv6 subnet for the GXW450X to reach using the static route.
Example:
IPv4 address – 192.168.66.4
IPv6 subnet – 2001:740:D::1/64
Netmask
Configure the subnet mask for the above destination address. If left blank, the default value is 255.255.255.255.
Example: 255.255.255.0
