83
“VOLTAGE MEASURE” menu.
Select the signal input channel according to the “SIGNAL SOURCE”.
Select the “peak-to-peak value” according to the “MEASURE TYPE”.
The corresponding icons and measured values will be displayed in the third option.
Display of the measurement results on the screen is changed with the change of the
measured signal.
Please regulate [Volt/div] or [s/div] if the reading of the “value” is displayed as ****
.
